Gas Cylinder Size Guide

Please find below the most common types of gas bottles that are available on the market.

You can use the sizes to find out which cage is most suitable for yourself. If you need help calculating this then please contact us with your requirements and we will be happy to help.

  • Patio Gas 5kg Propane

    314mm (h) x 306mm (d)

  • Patio Gas 13kg Propane

    580mm (h) x 315mm (d)

  • 3.9kg Propane

    340mm (h) x 240mm (d)

  • 6kg Propane

    495mm (h) x 256mm (d)

  • 13kg Propane

    580mm (h) x 315mm (d)

  • 19kg Propane

    810mm (h) x 315mm (d)

  • 47kg Propane

    1290mm (h) x 375mm (d)

  • 4.5kg Butane

    340mm (h) x 240mm (d)

  • 7kg Butane

    495mm (h) x 256mm (d)

  • 15kg Butane

    580mm (h) x 318mm (d)

  • 18kg Propane

    800mm (h) x 315mm (d)

  • 11kg Propane Flo Gas

    560mm (h) x 310mm (d)

  • Carbon Dioxide - Size: VB/LB

    500mm (h) x 140mm (d)

  • Carbon Dioxide - Size: LR/VR

    870mm (h) x 200mm (d)

  • Carbon Dioxide - Size: VK/LK

    1500mm (h) x 230mm (d)

  • Acetylene - Size: K

    370mm (h) x 180mm (d)

  • Acetylene - Size: M

    550mm (h) x 180mm (d)

  • Acetylene - Size: J

    850mm (h) x 200mm (d)

  • Acetylene - Size: A

    900mm (h) x 200mm (d)

  • Acetylene - Size: H

    1160mm (h) x 290mm (d)

  • Acetylene - Size: L

    1700mm (h) x 230mm (d)

  • Oxygen - Size: E

    500mm (h) x 150mm (d)

  • Oxygen - Size: X

    940mm (h) x 140mm (d)

  • Oxygen - Size: Y

    910mm (h) x 203mm (d)

  • Oxygen - Size: G20

    660mm (h) x 320mm (d)

  • Oxygen - Size: E33

    1300mm (h) x 230mm (d)

  • Oxygen - Size: W

    1460mm (h) x 230mm (d)

  • Oxygen - Size: E50

    1760mm (h) x 230mm (d)
